Small Bag Medicine Package Checkweigher After Pillow Packaging Machine Pharmaceutical Dynamic Checkweigher

Thedynamic checkweighercan detect products on the production line, track product quantity, weight, and other data, eliminate unqualified products, and distribute products to the area. Thesmall bag pharmaceutical checkweigherhas flexible customization capabilities, compact design, fast speed, high accuracy, stable operation, and convenient operation. Dynamic checkweigher can provide various rejection systems and integrate with upstream and downstream equipment into a complete packaging line. Any OEM and customer design orders are welcome! If you are interested in our products, please feel free tocontact us.

Dynamic checkweigher for pharmaceutical photos

Type SG-300

Weighing Range 5-3000g/5000g

Limited of product L: 350 W:300 H: 3mm

Accuracy ±0.5-1g Depends on product

Division Scale 0.1g

Belt Speed 0- 60 m/min

最高速度80 pc /分钟

Belt Width 300mm

Machine Weight 80kg+44kg

Power Supply AC 110/220V ±10% 50HZ

Power 100W

Main Material SU304 stainless steel

1st step: Customer has showed his special requirements.

2nd step: We try to understand the conception and pattern from customer with simple draft or refer picture.

3rd step: Making the conceptive CAD drawing based on communication and understanding.

4th step: Making the detail and 3D drawing agter fixed the design and other details.

第五步:提供报价after confirm the design,material and surface treament.

6th step: Making the sample for approval.

7th step: Testing installation after demo mock up.

8th step: Big production delivery and service after sales.

Strong practicality: 10 inch high color, high-resolution human-machine interface, easy to operate and friendly;

High stability: 24-hour high-speed and high-precision operation. Advanced and rigorous design concepts greatly reduce mechanical system failures and improve production efficiency;

High speed and precision: using high-speed and high-precision German HBM sensors

Material accessories: The entire body structure is made of 304 stainless steel, which is anti-theft, anti-corrosion, and has a long service life.

The weight inspection data is equipped with a standard USB interface and can be exported to Excel tables

Easy to maintain: Unique conveyor belt structure design, modular design, easy disassembly and cleaning, protection level IP65.

Easy to connect: Adopting a DC brushless motor, it is more stable and has a smaller and more refined structure. Suitable for larger speed requirements.

Easy to switch: can store 99 product formulas, and change product parameters with just one click.

-Leisure food: potato chips, biscuits, jelly, sweets, tea bags, instant noodles and other packaging.

-Agricultural products: rice bags, dried fruit net bags, grains, frozen products

-Daily cosmetics: bottled shampoo, makeup bags, and filled aerosols

-Hardware industry products: printing, toys, PCB boards, metal parts

-Pharmaceutical industry: bottle pills, small particle sachets, pulse bottles, etc.

Our service and strength

1. With over ten years of experience in professional quality testing equipment, we always pay attention to customer needs.

2. The use of digital intelligent and modular design with low maintenance cost and people-oriented approach provides excellent performance and convenient operation and maintenance.

3. Strong R&D and design capabilities can be customized according to customers' special requirements.

The Delivery Date: After receiving the payment, the delivery date will be within 15-30 working days

Packaging: Protective film + wooden case

Logistics: Air, sea or express (DHL, etc.)

The Freight: The cost of transport depends on the destination, mode of transport and the weight of the goods

Pay: T/T, Western Union, paypal

12 Months Guarantee

★ 12 months free main parts change (Please return the damaged parts by airmail)

★ Overseas engineers available (You only have to pay part of the freight)

Customization

All our machines can be customized , according to your product's features and your workshop environment, or your production line.

After-sales Service Provided

Engineers availbale to provide after-sales service overseas in order to help customers solve technical problems.
